View Issue Details Jump to Notes ]
IDProjectCategoryView StatusLast Update
0002288NetSurfLayoutpublic2015-03-15 00:28
ReporterSimon Smith
Assigned To
Product Version3.4
Target VersionFixed in Version
Summary0002288: Graphics image alignment incorrect
DescriptionThis may be due to my default 150% zoom factor, but it doesn't seem to go away if I zoom to 100%. Some of the equations embeddded in text on this page (and any others you may choose) have the incorrect vertical alignment.

For example in stage 5, last sentence, "If u1 > u2, the line is outside and therefore rejected." u1 > u2 is displayed about 1.5 lines too high.

Resizing the window causes some of the mathematical terms to 'jump' up and down. So if /all/ the formulae appear correctly, try zooming in and out or altering the window size. The problem should appear and disappear, affecting different images as the page reflows.
TagsNo tags attached.
Fixed in CI build #
Reported in CI build #2609
URL of problem pagehttp://en.wikipedia.org/w/index.php?title=Liang%E2%80%93Barsky_algorithm&redirect=no
Attached Files


Simon Smith


Simon Smith (reporter)

I've just noticed - the problem arises whenever there's a taller image on the same line, doesn't it?

-Issue History
Date Modified Username Field Change
2015-03-14 23:51 Simon Smith New Issue
2015-03-15 00:23 Simon Smith File Added: image alignment.jpeg
2015-03-15 00:26 Vincent Sanders Status new => acknowledged
2015-03-15 00:26 Vincent Sanders Product Version => 3.4
2015-03-15 00:26 Vincent Sanders Description Updated View Revisions
2015-03-15 00:28 Simon Smith Note Added: 0000769
